CarboCrackSeal R is a slow-reacting, highly elastic, two-component
polyurethane resin designed for injection applications.

Mixture viscosity

425 ± 60 MPa·s (23 °C)

Foaming factor

~1.0; glass transition temperature: –41 °C (wet)

Transition temperature

–41 °C (wet)

Applications

► Extended sealing and grouting of cracks and voids in buildings and other
concrete civil engineering structures

► Suitable for use in tunnel linings, parking decks, concrete foundations,
and dam diaphragms

► Injection waterproofing through hoses installed within concrete
structures

Component Description

CarboCrackSeal R Component A – Polyester polyols and additives.

CarboCrackSeal R Component B – Modified isocyanate.

Key Advantages

► Low-viscosity resin

► Maintains its elasticity throughout its entire service life after curing

► Excellent adhesion to both dry and damp surfaces

► Good tear resistance

► Low glass transition temperature, allowing it to withstand low-
temperature conditions without becoming brittle or being damaged by crack
expansion caused by temperature fluctuations

Operating Principle

When injecting the resin using a two-component pump, the resin components
are supplied separately in a 1:1 volume ratio and mixed immediately before
entering the packer by means of a static mixer installed in the injection
line. The resin mixture is injected into the crack or void being sealed
until the resin begins to emerge from the control outlets.

Packaging

CarboCrackSeal R Component A – 20 kg plastic canister.

CarboCrackSeal R Component B – 22 kg plastic canister.

Storage

Shelf life: At least 12 months from the date of manufacture when stored in
a dry place at temperatures between 10°C and 30°C.

Recommendations

The polymerization reaction can be accelerated by adding an accelerator.

Can be applied using a single-component pump.

Equipment

Compact single-component or two-component injection pumps with manual,
pneumatic, or electric drive, along with injection accessories such as
packers/sealing packers and embedded injection hoses.
